RGV car
product description
RGV is a rail-driven car. The main structure by the body, electrical control box, conveyor, track, slip line and other components. In the deployment of the system, RGV can automatically transport the cargo unit, the goods from one locations to another locations, you can achieve a multi-mouth, multi-mouth multi-mouth material transfer,
product features
1) Compared to AGV, RGV is a rail car, which needs to travel on the track, can be monorail, double or curved;
2) high speed and speed, the speed can go to 180m / min or more;
3) can be combined with a variety of equipment, which can be equipped with chain lines, drum lines, robots, etc., to adapt to different conditions;
4) RGV car can have a single station, double-bit response to different work efficiency occasions.
产品性能
序号 | 项 目 | 描 述 |
1 | 主体材质 | Q235 |
2 | 搬运单元数量 | 单工位一个货物单元，双工位两个货物单无 |
3 | 搬运单元尺寸 | 标准托盘1200*800/1000mm, 料箱600*400或按要求制作 |
4 | 货物单元重量 | 50～2000kg或按要求制作 |
5 | 运行速度 | 5～180m/min,变频调速 |
6 | 输送速度 | 5～30m/min，可选变频调速 |
7 | 控制方式 | 手动，半自动，联机全自动 |
8 | 电源电压 | 国内标准工频工业用电，3相，380V，50Hz |
10 | 供电方式 | 滑触线 |
11 | 定位方式 | 激光绝对定位，条码定位， |
12 | 定位精度 | ±5mm |
